40 x 60 Floor Plan with Elevation AutoCAD & PDF Download

40 x 60 -Floor Plan with Elevation

Plot Size: 40′ x 60′ – 03 Bedroom House Design, 3BHK
Building Type: Ground Floor -Approximate 2400 sqft
Purpose: Ideal for Joint Family

  • Hall: 14’-0” x 32’-0” (spacious central living area)

  • Bedroom 1: 12’-0” x 15’-0” (with attached toilet 4’ x 6’)

  • Bedroom 2: 12’-0” x 15’-0” (with attached toilet 4’ x 6’)

  • Bedroom 3: 10’-6” x 15’ (with attached toilet 3’-6” x 8’)

  • Kitchen 1: 9’-0” x 15’-0”

  • Kitchen 2: 9’-6” x 14’-6”

  • Verandah: 6’ x 15’ (front entrance)

  • Open Wash Area at back side

  • Open Space: both front and side for ventilation

30 x 40 Floor Plan with Elevation AutoCAD & PDF Download

30 x 40 -Floor Plan with Elevation

Plot Size: 30′ x 40′ – 02 Bedroom House Design, 2BHK
Building Type: Ground Floor -Approximate 1200 sqft
Purpose: Ideal for Single & Joint Family

Ground Floor Features

  • Bedroom 1: 11’8″ x 11’4″ – Rear-side bedroom with ample space and natural lighting.

  • Bedroom 2: 11’8″ x 11’6″ – Front-side bedroom attached with Toilet Size 4′ x 7’8”

  • Living Hall: 11’0″ x 15’10” – Centrally located spacious area for family gatherings and relaxation.

  • Dining Area: 7’8″ x 10’8″ – Placed between kitchen and bedrooms, ideal for easy access during meals.

  • Kitchen: 9’4″ x 10’8″ – Located at the back with direct access to Open Wash Area: 17’4″ x 4’0″

  • Store Room: 6’0″ x 4’0″ – Attached to the kitchen for pantry and storage use.

  • Toilet: 5‘0″ x 4’0″ – Common toilet located near the dining and bedrooms for easy accessibility.

  • W.C.: 4’0″ x 3′ 4″ – Separate water closet (toilet) for convenience.



30 x 40 Floor Plan with Elevation AutoCAD & PDF Download

30 x 40 -Floor Plan with Elevation

Plot Size: 30′ x 40′ – 01 Bedroom House Design, 1BHK
Building Type: Ground Floor -Approximate 1200 sqft
Purpose: Ideal for Single Family

Ground Floor Features

  • Bedroom located at the center-left side with the Size: 10′-0″ x 10′-0″

  • Attached Toilet adjacent to the bedroom with the Size: 4′-0″ x 7′-0″

  • Kitchen located at the rear-left corner with the Size: 8′-0″ x 10′-0″

  • Store Room attached to the kitchen with the Size: 4′-0″ x 6′-0″

  • Dining Room located at the rear-right side with the Size: 7′-8″ x 13′-4″

  • Entrance Room located at the front-right side with the Size: 5′-8″ x 8′-0″

  • Staircase provided near the bedroom and entrance area, offering access to the upper floors



30 x 46 Floor Plan with Elevation AutoCAD & PDF Download

30 x 46 -Floor Plan with Elevation

Plot Size: 30′ x 46′ – 02 Bedroom House Design, 2BHK
Building Type: Ground Floor -Approximate 1380 sqft
Purpose: Ideal for Joint Family

Ground Floor Features

  • Bedroom 1 located at rear-left side with the Size: 12′-0″ x 16′-4″ with Attached Toilet: 5′-0″ x 7′-4″

  • Bedroom 2 located at front-left side with the Size: 14′-0″ x 14′-0″

  • Living & Dining Room located at center with the Size: 10′-0″ x 12′-0″

  • Kitchen located at rear-right side with the Size: 11′-8″ x 13′-0″

  • Common Toilet located beside kitchen with the Size: 6′-0″ x 8′-0″

  • Entrance Room located at front-right side with spacious layout

  • Staircase provided near Living & Dining room for Roof access



40 x 60 Floor Plan with Elevation AutoCAD & PDF Download

40 x 60 -Floor Plan with Elevation

Plot Size: 40′ x 60′ – 02 Bedroom House Design, 2BHK
Building Type: Ground Floor -Approximate 2400 sqft
Purpose: Ideal for Joint Family

Ground Floor Features

Bedroom 1 located at rear side with the Size: 14′-0″ x 14′-0″ & Attached Toilet: 7′-0″ x 7′-0″ also attached Dressing Room: 7′-0″ x 6′-7″

Bedroom 2 located at Front side with the Size: 13′-6″ x 17′-10″ & Attached Toilet: 7′-0″ x 7′-6″ also attached Dressing Room: 6′-1″ x 7′-6″

Guest Room located at Rear side  with the Size: 10′-6″ x 14′-0″

Living Hall & Dining located at center of the building easy access to all the rooms  with the Size: 18′-10″ x 15′-8″

Kitchen located at front elevation with the Size: 11′-0″ x 14′-0″ attached Store Room  with the Size: 7′-0″ x 7′-0″ also attached Wash Area  with the Size: 7′-0″ x 7′-0″

Front elevation area designed for park one car

40 x 70 Floor Plan with Elevation AutoCAD & PDF Download

40 x 70 -Floor Plan with Elevation

Plot Size: 40′ x 70′ – 04 Bedroom House Design, including GF & FF 4BHK floor plan,
Building Type: Ground Floor & First Floor
Purpose: Ideal for Joint Family

Ground Floor Feaatures

  • Bedroom 1 –Located in rear side with attached dressing & Toilet

  • Bedroom -2 Located in Front side with attached dressing & Toilet

  • Living Hall & Dining:  designed at centre of the house access to all area

  • Guest Room: perfect for hosting guests or formal meetings.

  • Kitchen: spacious kitched with attached store room also direct access to outside opn sapace

  • Porch:  Covered parking area with a pathway to the main entrance.

First Floor Feature

Bedroom 1 –Located in center of the house with attached dressing & Toilet

Bedroom -2 Located in Front side with attached dressing & Toilet

Balcony and sitout area designes in this first floor plan

40 x 80 -2BHK Floor Plan with Elevation AutoCAD & PDF Download

40 x 80 -2 BHK Floor Plan with Elevation

Plot Size: 40′ x 80′ – 02 Bedroom House Design 2BHK floor plan,
Building Type: Ground Floor with Guest Room Facility
Purpose: Ideal for Joint Family

40′ x 80′-2BHK House Floor plan

  • Bedroom 1 : Size in this plan 18’0″ x 13’0″ – A large and comfortable bedroom with attached dressing room  and toilet for privacy, Dress Room : Size in this plan 6’0″ x 8’0″ , Toilet  Size in this plan 9’0″ x 8’0″

  • Bedroom -2  Size in this plan 14’0″ x 17’4″ – with attached dress and toilet, Dressing Room  Size in this plan 6’8″ x 8’0″  & Toilet (Second Bedroom): Size in this plan 6’8″ x 9’0″ –

  • Living Hall & Dining: Size in this plan 19’2″ x 21’2″ – Centralized easy access to any room

  • Guest Room: Size in this plan 15’0″ x 20’0″ – A spacious room with bay windows, perfect for hosting guests or formal meetings.

  • Kitchen: Size in this plan 14’5″ x 13’0″ – Well-planned cooking space with attached access to the wash and store Room.

  • Common Toilet: Size in this plan 7’0″ x 4’0″

  • Porch: Size in this plan 18’0″ x 16’0″ – Covered parking area with a pathway to the main entrance.
